July 4, 2020

Creating R Shiny apps has been useful in class demonstration, project assignments, and customized tests. However, to host and share these apps, a server is needed. I have tried three options so far: Shinyapps.io, Amazon Web Service (AWS), and Linode.

---

Shinyapps.io

This is the easiest way. In RStudio IDE, the Publish button deploys the Shiny apps to RStudio’s web host for shiny apps: https://www.shinyapps.io/. Here is the full tutorial from RStudio.

A free plan on shinyapps.io has limits on run-time and number of deployed apps. Still, it is a good way for getting started with Shiny apps. Plans on shinyapps.io are pricy comparing with AWS and Linode.

---

Amazon Web Service (AWS)

We are on our own to set up a shiny server (and more) in the AWS Elastic Compute Cloud (EC2). Charles Bordet wrote a wonderful step-by-step installation guide, The Ultimate Guide to Deploying a Shiny App on AWS.

The general purpose (burstable) instance families include T2 (July 2014), T3 (August 2018) and T3a (April 2019), each comes with a variety of capacity (nano / micro / small / medium / large / xlarge) in memory sizes and vCPUs. A new generation is 10% cheaper than the previous generation.

Amazon generously offers a one-year Free Tier plan (t2.micro / 1GB Memory / 1 vCPU / 8 GB Storage) Afterwards, users can choose from a handful of pricing plans, such as On-Demand and 1-year or 3-year Saving Plans. Users can estimate the cost. Below is a comparison of t3a.micro 3-year Saving Plan with Linode’s entry-level plan.

Plan	Memory	vCPUs	Storage	Monthly Price
t3a.micro	1 GB	2	20 GB	$4.99
Linode	1 GB	1	25 GB	$5.00

I started with 8 GB elastic block storage (EBS) and went up to 20 GB. Resizing requires two steps:

1. Modifying an EBS volume using Elastic Volumes. This can be done in the AWS console.

2. Extending a Linux file system after resizing a volume. This needs to be done in a terminal.

---

Linode

Since I have learned how to set up a Shiny server on AWS, getting started in Linodes seems easier and faster. Here is Linode’s guide: Getting Started with Linode. By the way, besides using the terminal to type commands, Linode provides a web-based shell, the Linode Shell (Lish) in the account interface.

Below are my notes for quick future reference.

Secure Your Server. Login as root on Linode to add a limited user account.

Enable SSH key pairs. Login to Linode example_user, create a .ssh folder and grant read / write / execute permission. On Mac OS terminal, check existing keys, generate a key pair, and upload the public key to Linode. Back to Linode. Add CRAN repo and install R 3.6. Install Shiny server. First install the Shiny package in R, then use GDebi to install shiny-server. Hide directory by setting directory_index off; in shiny-server.conf.

# Instruct Shiny Server to run applications as the user "shiny"
run_as shiny;

# Define a server that listens on port 3838
server {
  listen 3838;

  # Define a location at the base URL
  location / {

  # Host the directory of Shiny Apps stored in this directory
  site_dir /srv/shiny-server;

  # Log all Shiny output to files in this directory
  log_dir /var/log/shiny-server;

  # When a user visits the base URL rather than a particular application,
  # an index of the applications available in this directory will be shown.
  directory_index off;
  }
}

Reload Shiny server after making changes in shiny-server.conf. Install more R packages. Upload shiny apps from Github and create shortcut links in the /srv/shiny-server folder. Error messages can be found in the folder /var/log/shiny-server. Alternatively, we can transfer files between local drive and Linode in Mac OS Terminal (not in Linode!). Use NGINX to set up reverse proxy so that the app can be access by example.com/app_name instead of xxx.xxx.xxx.xxx:3838/app_name. (80 is the default port number for the website. The configuration redirects example.com to Shiny’s port 3838)

http {
        # Basic Settings

        # Hide version number
        server_tokens off;

        map $http_upgrade $connection_upgrade {
            default upgrade;
            ''      close;
        }
}

server {
    listen 80;
    listen [::]:80;

    server_name example.com;
    location / {
        proxy_pass http://localhost:3838;
        proxy_redirect http://localhost:3838/ $scheme://$host/;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection $connection_upgrade;
        proxy_read_timeout 20d;
        proxy_buffering off;
    }
}

Check NGINX configuration and restart NGINX server. Secure HTTP Traffic with Certbot Update the shiny.conf file to enforce HTTPS connections only, TLS Deployment Best Practices. Make sure the lines and block commented by # managed by Certbot are already in place.

server {
    listen 443 ssl http2 ipv6only=on; # managed by Certbot
    listen [::]:443 ssl http2; # managed by Certbot

    # HSTS max-age=31536000 seconds means one year
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;

    server_name example.com;
    location / {
        proxy_pass http://localhost:3838;
        proxy_redirect http://localhost:3838/ $scheme://$host/;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection $connection_upgrade;
        proxy_read_timeout 20d;
        proxy_buffering off;
    }
}

server {
    if ($host = example.com) {
        return 301 https://$host$request_uri;
    } # managed by Certbot

    listen 80;
    listen [::]:80;

    server_name example.com;
    return 404; # managed by Certbot
}

Again, check NGINX configuration and reload it. Optional firewall configuration.

Optional RStudio server installation. NGINX reverse proxy is needed as well.
